Wires and Bars

At the Stolberg site, Aurubis produces round, square and hexagonal wires and bars with a wide range of dimensions as well as a large selection of special profiles.

The delivery presentations on coils, in drums, as package winding or ring material offer a wide range of winding types and processing weights.

The focus is on markets where the specific and especially conductivity-related properties of copper and copper alloys offer our customers added value. Customers benefit from our quality, productivity, process efficiency and innovative strength.

Quality assurance

The Aurubis production site in Stolberg is IATF 16949 and DIN EN ISO 9001:2015 certified.

Dimensions
Wires drawn (All dimensions in mm)
Product Round Square Hexagon

Flat

Profiles
Brass leaded

2,0 – 14,5

3,5 – 12,0

3,5 – 12,0

2,0 – 14,0*

Cross section** 10 – 150 mm²

Lead free brass

2,0 – 14,5

3,5 – 12,0

3,5 – 12,0

2,0 – 14,0*

Cross section** 10 – 150 mm²

Copper

2,0 – 14,5

3,5 – 12,0

3,5 – 12,0

2,0 – 14,0*

Cross section** 10 – 150 mm²

* Assignment width and height on request.
** Circumscribed circle max. 14 mm.

Delivery forms

Packages, spooled (with and without cardboard core)

Inner Ø (mm)



Installation width (mm)



Max. Outer Ø (mm)



Weight (kg)



630

350

1.150

500 - 1.200

710

350

1.150

500 – 1-100

710

200

950

300 - 350

500

450

1.000

500 – 1.200

500

500

1.000

450 – 550

359

278

740

500 – 1.200

Iron coil

Bore-Ø (mm)



Installation width (mm)



Max. Outer Ø (mm)



Weight (kg)



80

520

1.050

500 – 1.200

 Rings

Inner Ø (mm)



Installation width (mm)



Max. Outer Ø (mm)



Weight (kg)



450

50 – 150

750

30 – 80

550

70 – 200

850

50 – 120

800

80 - 250

1.000

150

 Crown canes

Height (mm)

Max. Foot Ø (mm)

Crowns Ø (mm)



Weight (kg)



800 – 1.500

1.000

ca. 480

250 – 1.000

Large coils
(with or without cardboard core)

Inner Ø (mm)



Installation width (mm)



Max. Outer Ø (mm)



Weight (kg)

600

Max. 1.000

1.400

Max. 4000

Schweißstäbe
(lose in Kisten oder in Plastikbeuteln je 10 / 25 kg)

Length (mm)

Wide (mm)

Height (mm)

Content (kg)

1.050

320

100

100

1.050

420

300

500

1.050

570

320

1.000

 Draht in Fässern

Inner Ø (mm)



Height (mm)

Max. Outer Ø (mm)



Weight (kg)



400

600

630

Max. 250
